| Optical Fiber Type | Single Mode | Multi-mode | |
| Insertion Loss | Typ.(dB) | 0.35 | 0.35 |
| Max.(dB) | 0.75 | 0.75 | |
| Low Insertion Loss | Typ.(dB) | 0.1 | 0.1 |
| Max.(dB) | 0.35 | 0.35 | |
| Return Loss | ≥60（APC） | ≥200（PC） | |
| ≥50（PC） | |||
| Male/Female Connector | Male Connector: With pin | Female connector:Without pin | |
| Durability（dB） | ≤0.2 500times | ||
| Operation Temp.（℃） | -20 - +70 | ||
| Test Wavelength（nm） | 1310 | 850 | |
Conventional Connectors like LC/SC/FC
| Optical Fiber Type | Single Mode | Multi Mode | |
| Connector Type | PC | APC | PC |
| Insertion Loss(dB) | ≤0.3 | ||
| Return Loss(dB) | ≥50 | ≥60 | ≥35 |
| Durability（dB） | ≤0.2 1000times connecting | ||
| Operating Temp.（℃） | -20 - +70 | ||
| Testing Wavelength（nm） | 1310 | 850 | |
