产品特性
产品支持QSFP28 MSA、CFP MSA、SWDM4等协议
产品速率包括103.125G、112G
商业级/工业级应用
应用
100G以太网
InfiniBand
CPRI/eCPRI
规格参数
| Type | Part Number | Package | Data Rate | Wavelength | Reach | Transmitter | Receiver | TX output (dBm) | RX Sensitivity (dBm) | Power Consumption (W) | Interface | Temperature | Application |
| 100G QSFP28 SR4 | FLS100C010S | QSFP28 | 100G | 850nm | 100M | VCSEL | PIN | 2.4~-8.4 | -7.4 | <3.5 | MPO-8 | 0℃~70℃ | 100GBASE-SR4 |
| 100G QSFP28 AOC | FLS100C003S-Lxx | QSFP28 | 100G | 850nm | 0.5M~30M | VCSEL | PIN | - | - | - | AOC | 0℃~70℃ | 100GBASE-SR4 |
| 100G QSFP28 SWDM4 | FLS100C011S | QSFP28 | 100G | 850-940nm | 100M | VCSEL | PIN | 3~-5.5 | -8.2 | <3.5 | LC | 0℃~70℃ | SWDM MSA |
| 100G QSFP28 CWDM4 | FLS100C112S | QSFP28 | 100G | CWDM | 2KM | DFB | PIN | 2.5~-6.5 | -10 | <3.5 | LC | 0℃~70℃ | 100GBASE-CWDM4 |
| FLS100C210S | QSFP28 | 100G | CWDM | 10KM | DFB | PIN | 2.5~-6.5 | -11.5 | <3.5 | LC | 0℃~70℃ | 100GBASE-CWDM4 | |
| 100G QSFP28 LR4 | FLS100C211S | QSFP28 | 100G | LWDM | 10KM | DFB | PIN | 4.5~-4.3 | -10.6 | <3.5 | LC | 0℃~70℃ | 100GBASE-LR4 |
| FLS100C212S | QSFP28 | 100G | LWDM | 10KM | DFB | PIN | 4.5~-4.3 | -10.6 | <3.5 | LC | 0℃~70℃ | 100GBASE-LR4/OTU4 | |
| FLS100C910S-RX | QSFP28 | 100G | LWDM | 10KM | - | PIN | - | -10.6 | <2 | LC | 0℃~70℃ | 100GBASE-LR4 | |
| 100G QSFP28 ER4 | FLS100C240S | QSFP28 | 100G | LWDM | 40KM | EML | APD | 4.5~-2.9 | -18.6 | <3.5 | LC | 0℃~70℃ | 100GBASE-ER4 |
| 100G QSFP28 ZR4 | FLS100C280S | QSFP28 | 100G | LWDM | 80KM | EML | PIN+SOA | +2.0~6.5 | -28 | <6.5 | LC | 0℃~70℃ | 100GBASE-ZR4 |
| 100G CFP LR4 | FLS100C511S | CFP | 100G | LWDM | 10KM | EML | PIN | 4.5~-4.3 | -10.6 | <8 | LC | 0℃~70℃ | 100GBASE-LR4 |
| FLS100C610S | CFP2 | 100G | LWDM | 10KM | EML | PIN | 4.5~-4.3 | -8.6 | <6 | LC | 0℃~70℃ | 100GBASE-LR4 | |
| 100G CFP2 LR4 | FLS100C511S | CFP | 100G | LWDM | 10KM | EML | PIN | 4.5~-4.3 | -10.6 | <8 | LC | 0℃~70℃ | 100GBASE-LR4 |
| FLS100C610S | CFP2 | 100G | LWDM | 10KM | EML | PIN | 4.5~-4.3 | -8.6 | <6 | LC | 0℃~70℃ | 100GBASE-LR4 | |
| 100G QSFP28 DR1 | FLS100C301S | QSFP28 | 100G | 1310nm | 500m | EML | PIN | -2.9~4.0 | max(-3.9，SECQ-5.3) | <4 | LC | 0℃~70℃ | 100GBASE-DR |
| 100G QSFP28 FR1 | FLS100C302S | QSFP28 | 100G | 1310nm | 2KM | EML | PIN | -3.1~4.0 | max(-4.5，SECQ-5.9) | <4 | LC | 0℃~70℃ | 100GBASE-FR |
| 100G QSFP28 LR1 | FLS100C303S | QSFP28 | 100G | 1310nm | 10KM | EML | PIN | -0.2~6.6 | max(-6.1，SECQ-7.5) | <4 | LC | 0℃~70℃ | 100GBASE-LR |
