| Type | Part Number | Package | Data Rate | Wavelength | Reach | Transmitter | Receiver | TX output (dBm) | RX Sensitivity (dBm) | Power Consumption (W) | Interface | Temperature | Application |
| 200G QSFP56 SR4 Transeiver | FLS200C010S | QSFP56 | 200G | 850nm | 100m | VCSEL | PIN | -6.5~4 | -8.4 | <4 | MPO-8 | 0℃~70℃ | 200GBASE-SR4 |
| 200G QSFP56 A0C | FLS200C003S-Lxx | QSFP56 | 200G | 850nm | 30m | VCSEL | PIN | - | - | <4 | AOC | 0℃~70℃ | 200GBASE-SR4 |
| 200G QSFP-DD LR4 Transeiver | FLS200C100S | QSFP-DD | 200G | LWDM | 10km | EML | PIN | -0.4~5.1 | -7.7 | <9 | LC | 0℃~70℃ | 200GBASE-LR4 |
| 400G QSFP-DD SR8 Transeiver | FLS400C010S | QSFP-DD | 400G | 850nm | 100m | VCSEL | PIN | -4.5~3 | -6.5 | <10 | MPO16 | 0℃~70℃ | 400GBASE-SR8 |
| 400G QSFP-DD AOC | FLS400C003S-Lxx | QSFP-DD | 400G | 850nm | 100m | VCSEL | PIN | - | - | - | AOC | 0℃~70℃ | 400GBASE-SR8 |
| 400G QSFP-DD DR4 Transeiver | FLS400C005S | QSFP-DD | 400G | 1310nm | 500m | EML | PIN | -0.8~4.2 | -4.4 | <10 | MPO-8 | 0℃~70℃ | 400G DR4 |
| 400G QSFP-DD FR4 Transeiver | FLS400C020S | QSFP-DD | 400G | CWDM | 2km | EML | PIN | -0.2~3.7 | -4.6 | <10 | LC | 0℃~70℃ | 400GE FR4 |
